Dell PowerVault DL2000 - Manual (Page 3)

hardware: dL2000
Value Series 1 processor (Quad-Core Intel® Xeon® E5410, 2x6MB Cache, 2.33GHz, 1333MHz FSB) and 8GB RAM
Performance Optimized
2 processor (Quad-Core Intel® Xeon® E5410, 2x6MB Cache, 2.33GHz, 1333MHz FSB), 16GB RAM and DRAC
(Dell Remote Access Card)
Internal Storage 2 x 250GB, 7200 RPM, SATA II drives in hardware RAID 1 configuration
external Storage Connectivity Available through 1 or 2 PERC 6/E
Tape Connectivity SAS 5/E HBA; U320 SCSI HBA; Fiber Channel HBAs: Emulex or QLogic HBAs
Networking Dual-embedded Broadcom® NetXtreme II™ 5708 Gigabit6 Ethernet NIC with fail-over and load balancing.
Operating System Windows® Server 2008, Standard, x64
Systems Management OpenManage™, ITA and Dell Management Console
remote Management DRAC
Physical dimensions
2U rack mountable chassis
29.31" (74.4cm) D x 17.5" (44.43cm) W x 3.4" (8.64cm) H with bezel attached
Rack weight 50.71 lbs. (23 kg), maximum configuration
Ports Rear: 2 x USB 2.0, 1 x serial connector, 1 x video connector, 1 x RJ45 for DRAC 5/i connector
POwerVauLTLT Md1000 exTerNaL STOTOrage FeaTureS INCLuded wITh The POwerVauLTLT dL2000
hard drives Available in only eight (8) or fifteen (15) 1-inch x 3.5-inch SATA II hot-pluggable 3.0 Gbps hard drives
drives available 7200 RPM SATA II: 500GB, 750GB or 1TB; 5400 RPM Energy Efficient SATA II: 1TB
Maximum Scalability
Up to 6 MD1000 shelves connected to one dual-ported PERC card; Up to a total of 12 MD1000s shelves
using two PERC cards in a DL2000
Maximum usable Capacity Up to 144TB of usable space (180TB of raw disks) 32 GB
Physical Height: 13.11 cm (5.16") H x 44.63 cm (17.57") W x 48.01 cm (18.9") D
Weight: 35.37 kg (78 lbs.) (maximum configuration)
Power Supplies Wattage: 488W maximum continuous; 550W peak
Heat dissipation: 200W
Voltage: 100-240V rated (actual 90-264V)
Frequency: 47-63Hz
Amperage: 7.2A at 100V, 3.6A at 200V
SIMPLIFy yOur NeTwOrk aT deLL.COMCOM/dL2000
