Installing the VoIP Loudspeaker Amplifier
Configure the Loudspeaker Amplifier Parameters
VoIP Loudspeaker Amplifier Operations Guide 930111F CyberData Corporation
15
Figure 2-12. Home Page
3. On the Home Page, review the setup details and navigation buttons described in Table 2-8 .
Table 2-8. Home Page Overview
Web Page Item Description
Device Name Shows the device name.
Running Shows the current speaker function.
Serial # Device serial number.
Ethernet Address Device ethernet address.
IP Addressing Shows the current IP addressing setting (DHCP or static).
IP Address Shows the current IP address.
Subnet Mask Shows the current subnet mask address.
Default Gateway Shows the current default gateway address.
Link to the Speaker Setup page.
Link to the Network Setup page.
Link to the SIP Setup page.
Link to the MGROUPS Setup page.
