Dell Alienware M17x (Mid 2009) - Manual (Page 5)

05
05
/
SPECIFICATIONS
Communications
Network adapter
10/100/1000 Ethernet LAN on system board
Wireless
WLAN Mini-Card (half Mini-Card size slot) •
WPAN, Bluetooth card (full card size slot) •
Modem:
Type
External V.92 56K USB Modem
Controller Hardware Modem
Interface Universal Serial Bus (USB)
Video
Type
combination of chipset integrated Graphics
and discrete MXM Graphics cards
LCD interface Low Voltage Differential Signaling (LVDS)
External display support VGA, HDMI 1. 2, DisplayPort
Graphics devices NVIDIA Geforce 9400M G (Integrated •
Graphics) with 256MB of video memory
shared from system memory
NVIDIA Geforce 280M SLI (Dual MXM
•
Graphics cards) each with 1GB of dedicated
video memory
NVIDIA Geforce 260M single/SLI (Single or
•
Dual MXM Graphics cards) each with 1GB of
dedicated video memory
Graphics card specification MXM 3.0 Type B compliant cards with total
power up to 75W each
Audio
Type
High-Definition 5.1 Surround Sound Audio
Controller IDT 92HD73C HDA Codec
Stereo conversion 24-bit (analog-to-digital and digital-to-analog)
Internal Interface High Definition Audio
Speaker dual 8-ohms speakers in both the left and right
speaker assembly
Internal speaker amplifier up to 5 W per channel; up to 10 W total power
Internal microphone support dual digital array microphones in the display
assembly
Volume controls program menus, media control buttons
Audio connectors microphone connector input; three stereo
headphone/speaker connectors capable of
supporting 5.1 audio (see the Mobile Manual
for more information on the number of audio
connectors)
Camera
Pixel
2.0 megapixel
Video resolution 320 x 240 - 1600 x 1200 (640 x 480 at 30 fps)
Diagonal viewing angle 66°
