Dell Alienware M17x (Mid 2009) - Manual (Page 4)

04
04
/
SPECIFICATIONS
Processor and System Chipset
BIOS EPROM
16 Mbit
Graphics bus Dual PCIE x 8 buses supporting single or dual x
8 PCIE MXM 3.0 GFX cards
PCI Bus 32 bits
ExpressCard
Controller
NVIDIA GeForce 9400M G
Connector one ExpressCard slot (54 mm)
Cards supported ExpressCard/34 (34 mm)
ExpressCard/54 (54 mm) 1. 5 V and 3. 3 V
Connector size 26 pins
IEEE 1394/Media Card
IEEE 1394/Media Card
controller
PCI Based Ricoh R5C833-T
IEEE 1394 Interface compliant with standard IEE1394a-2000
specification
Media Card Formats 8-in-1 Card Reader Support
Secure Digital (SD) memory card •
Secure Digital High Capacity (SDHC) card •
Secure Digital Input/Output (SDIO) card •
Multi Media Card (MMC) •
Memory Stick •
Memory Stick PRO •
xD-Picture Card (type - M and type - H) •
Hi Density-SD (SDHD) •
Memory
Connectors
two internally-accessible DDR3 SODIMM
sockets
Capacities 2 GB to 8 GB
Memory types 1067 MHz, 1333 MHz
(dual channel configurations)
Memory configurations
possible
2 GB, 3 GB, 4 GB, 6 GB, and 8 GB
Ports and Connectors
IEEE 1394a
4-pin serial connector
Network adapter RJ45 connector 10/100/1000
USB four 4-pin USB 2.0-compliant connectors
eSATA one 4-pin eSATA/USB combo connector
VGA 15-hole connector
HDMI 19-pin connector
DisplayPort 20-pin connector
