23 Setting Up Dell™ DR Series Deduplication Appliance as Backup Target on CommVault SimpanaTM 10 | January 2014
12. In the Add Disk Library dialog box, enter Alias and check Enable replication checkbox.
NOTE:
Enable Replication:
• For Disk Library Replication solution, select this option to use ContinuousDataReplicator to
replicate data between the source (shared folder added in Step 7) and the destination (shared
folder added in Step 10) mount paths. Leave this option unselected if you don’t want CommVault
to manage replication between the two DRs.
• Selecting this option will automatically create a new replication set and a replication pair under
ContinuousDataReplicator, when a mount path is added to this library. These replication sets and
replication pairs can be monitored from the CommCell Console. It is highly recommended not to
change the default settings of the replication sets, or delete the replication sets when the
replication is in progress.
• If this option is selected, make sure to install the ContinuousDataReplicator package on the
source and the destination computers before adding mount path to this library.Click OK.
• If this option is not selected, use DR native replication between two separate disk libraries. There
may exist issues when CommVault tries to restore from the target DR disk library, because
CommVault doesn’t have catalog information for that disk library.
Name of the disk library
Unselected to use DR replication/selected to use
CV replication
