Dell Powervault LTO6 - Manual (Page 9)

Chapter 1. Introduction
v “Overview”
– “Serial Attached SCSI (SAS) Interface” on page 1-2
v “Encryption” on page 1-2
v “Specifications and Features” on page 1-3
v “Tape Backup Software” on page 1-4
v “Front Panel” on page 1-4
v “Rear Panel” on page 1-6
Overview
The LTO PowerVault tape drive is a high-performance, high-capacity tape storage
device that is designed to back up and restore data and archive and retrieve files
in an Open Systems environment. The drive can be integrated into a system
(internal model) or can be provided as a separately packaged desktop unit
(external model). There are six generations of the Dell PowerVault tape drives in
the LTO series of products.
Figure 1-1 shows the internal model of the tape drive. Figure 1-2 on page 1-2
shows the separately purchased external model of the tape drive. Figure 1-3 on
page 1-2 shows the rack mount model.
a80hd004
Figure 1-1. PowerVault Internal Model
1-1
