Installing the Display Assembly
Installing the Display Assembly
1. Attach the display assembly to the base of the computer.
2. Tighten the screws to secure the display assembly.
3. Connect the low-signal differential signaling (LVDS) cable to the system board.
4. Connect the camera cable to system board.
5. Push the antenna through the opening to the bottom of the computer.
6. Secure the antenna cable to the routing channels.
7. Connect the antenna to the WLAN/WLAN cards.
8. Replace the palm rest .
9. Replace the CPU door
10. Replace the keyboard .
11. Replace the keyboard trim .
12. Replace the optical drive .
13. Replace the hard drive .
14. Replace the back panel .
15. Replace the battery .
16. Follow the procedures in After Working Inside Your Computer .
Related Links
Removing the Display Assembly
