About Your Monitor  13
1920 x 1080 67.5 60.0 193.5
2560 x 1440 88.8 60.0 241.5
3840 x 2160 133.3 60.0 297.0
5120 x 2880* 85.6 30.0 238.3
5120 x 2880* 177.7 60.0 483.3
* To display 5120 x 2880 at 60 Hz and 30 Hz, both DP1 and DP2 must be
connected. DP source’s graphics card must be DP1.2 certified and Tile display
feature, capable of supporting resolution up to 5120 x 2880 at 60Hz and its
driver supports DisplayID v1.3.
Electrical Specifications
Video input signals Digital video signal for each differential line,
predifferential line at 100 ohm impedance. DP1.2
signal input support
AC input voltage/
frequency/current
100 to 240 VAC/50 or 60 Hz ± 3 Hz/2.4 A (Max.)
Inrush current 120 V:40 A (Max.)
240 V:80 A (Max.)
Speaker Specifications
Speaker rated power 2 x 16 W
Frequency Response 200 Hz - 20 kHz
Impedance 4 ohm
Physical Characteristics
Connector type DisplayPort connector.
Mini DisplayPort connector.
USB 3.0 update stream port connector.
USB 3.0 down stream port connector x 5.
(Port with
lightning icon is for BC 1.2)
Signal cable type • Digital: detachable, DisplayPort to Mini
DisplayPort 1.8 M cable.
• Digital: detachable, DisplayPort to
DisplayPort 1.8 M cable.
• Digital: detachable, Mini DisplayPort to
Mini DisplayPort 1.8 M cable.
• Digital: detachable, USB 3.0 1.8 M cable.
Dimensions (with stand)
Height (extended)
542.1 mm (21.3 inches)
