Removing

the

Keyboard |

19

4

Lift and slide the keyboard towards the display to release the keyboard from the
palm-rest and place the keyboard on the palm-rest.

5

Lift the connector latch and disconnect the keyboard cable from the

keyboard-cable connector.

6

Lift the keyboard off the palm-rest.

1

keyboard

2

palm-rest

3

keyboard cable

4

connector latch

4

3

1

2
