Dell™ 1250c Color Printer
Quick Reference Guide
About Your Printer Locating the Service Tag
1 Operator Panel 2 Output Tray
3 Output Tray Extension 4 Print Head Cleaning Rod
5 Toner Access Cover 6 Power Switch
7 Paper Width Guides 8 Multipurpose Feeder (MPF)
9 Front Cover 10 Length Guide
11 MPF Extension 12 Paper Cover
1 (Jam) indicator • Indicates that a paper jam occurred or the rear cover
is open.
2 (Toner) indicator • Indicates that the toner is low or empty, or toner error
occurred.
3 (Error) indicator Indicates that an error occurred.
4 (Ready/Data) indicator Indicates the printer status, such as receiving and printing
data.
5 (Start) button/indicator • Press this button to start duplex printing after loading
paper.
• Press and hold this button to print the Report pages.
6 (Cancel) button Press this button to cancel a job or clear an error.
7 (Manual Duplex) indicator Indicates that the printer is ready to print the second side
(odd) pages for duplex printing.
8 (Load Paper) indicator Indicates that no paper is loaded or a paper jam occurred
in the multipurpose feeder.
Loading Letterhead
Load the letterhead in the printer with the print-side facing up. Ensure that the title on the
letter head enters the printer first.
www.dell.com | support.dell.com
1
6 5 7 10 11 12 9 8
4 2 3
1
4
2
3
5 5
September 2010
Service Tag Express Service Code
xxxxxxx 000 000 000 00
