Internal Card With Bluetooth® Wireless Technology
Dell™ Vostro™ 1520 Service Manual
Removing the Internal Card With Bluetooth Wireless Technology
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery from the computer.
3. Remove the hard drive and mini-card access panel from the computer.
4. Remove the hard drive from the computer.
5. Remove the WLAN card from the computer.
6. Remove the hinge cover from the computer.
7. Remove the keyboard from the computer.
8. Remove the display assembly from the computer.
9. Remove the palm rest from the computer.
10. Remove the screw that secures the Bluetooth module to the system board.
11. Lift the edge of the Bluetooth module closest to the front of the computer and lift the module from its slot.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
