Feature Specification
Mini-Tower, Small Form Factor one 164-pin connector
Serial ATA:
Mini-Tower four 7-pin connectors
Small Form Factor three 7-pin connectors
Memory four 240-pin connectors
Internal USB:
Mini-Tower one 10-pin connector
Small Form Factor none
System Fan one 5-pin connector
Front panel control:
Mini-Tower one 6–pin and two 20–pin connector
Small Form Factor one 6-pin, one 10-pin, one 12-pin and one 20-pin connector
Mini-Tower – Thermal Sensor one 2-pin connector
Processor one 1150-pin connector
Processor Fan one 5-pin connector
Service mode jumper one 2-pin connector
Password clear jumper one 2-pin connector
RTC reset jumper one 2-pin connector
Internal speaker one 5-pin connector
Intruder connector one 3-pin connector
Power connector: one 8-pin. one 4-pin, one 6-pin, connector
Table 26. Controls and Lights
Feature Specification
Front of the computer:
Power button light White light — Solid white light indicates power-on state; blinking
white light indicates sleep state of the computer.
Drive activity light White light — Blinking white light indicates that the computer is
reading data from or writing data to the hard drive.
Back of the computer:
Link integrity light on integrated network
adapter Green — a good 10 Mbps connection exists between the network
and the computer.
Green — a good 100 Mbps connection exists between the network
and the computer.
