Page 29

3. Align two bottom insert pins on cable 4. Once the insertion is done, gently

cover to corresponding holes on the

push the cable cover down towards

monitor rear, then gently insert the

the monitor, until the rest of insert pins

pins into the small holes provided.

click into place.

Wall Mounting (Optional)

(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible base
mounting kit.

1. Place the monitor panel on a soft cloth or cushion on a stable, flat

table.

2. Remove the stand.
3. Use a screwdriver to remove the four screws securing the plastic

cover.

4. Attach the mounting bracket from the wall mounting kit to the LCD.

5. Mount the LCD on the wall by following the instructions that came

with the wall mounting kit.

NOTE: For use only with UL-listed wall mount bracket with minimum
weight/load bearing capacity of 9 kg.

Setting Up the Monitor


