Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The
monitor automatically provides the computer with its Extended Display
Identification Data (EDID) using Display Data Channel (DDC) protocols
so that the system can configure itself and optimize the monitor settings.
Most monitor installations are automatic. You can select different settings
if required.
Flat-Panel Specifications
Model number Dell P2714H monitor
Screen type Active matrix - TFT LCD
Panel type In Plane Switching
Viewable image
dimensions
Diagonal 68.6 cm (27.0
inches)
Horizontal 597.9 mm
Vertical 336.3 mm
Pixel pitch 0.1 mm
Viewing angle:
Horizontal
Vertical
178° typical
178° typical
Luminance output 300 cd/m² (typical)
Contrast ratio
1000 : 1 (typical)
2 Million : 1 (typical dynamic
contrast ratio on)
Faceplate coating
Antiglare with hard-coating
3H
Backlight LED light bar system
Response time 8ms Typical (G to G)
Color depth 16.7 mil colors
Color gamut 83 % (typical) **
** [P2714H] color gamut (typical) is based on CIE1976 (83 %) and CIE1931
(72 %) test standards.
