NOTE: Please follow the same procedure to remove the right display hinge.
Installing The Display Hinges
1. Align the display hinge in the appropriate position.
2. Tighten the screws to secure the left display hinge.
3. Connect the low-voltage differential signalling (LVDS) and wireless cables
on the left display hinge.
4. Install the display bezel .
5. Install the display panel .
6. Install the display assembly .
7. Install the palm rest .
8. Install the hard drive .
9. Install the keyboard .
10. Install the base cover .
11. Install the battery .
12. Follow the procedures in After Working Inside Your Computer .
NOTE: Please follow the same procedure to install the right display hinge.
