Page 30
CHAPTER 3: INSTALLATION
3-10
FOT-F3 USER’S MANUAL
Figure 3-4 Surface Mounting the FOT-F3
3.4.2
Cable Strain Relief for Non-Mounted FOT-F3
To relieve the strain to cables connected to a FOT-F3 that is not
surface mounted, proceed as follows:
1.
If possible, use long tie wraps to secure the FOT-F3 to a
structural support such as a beam or a rafter.
2.
Using additional long tie wraps, secure each cable to the
same structural support.
DEVICE
FOT-F3
Tie Wraps
Fiber Optic
Segment
Cable Mounts
AUI Cable
0461-09
