Pinnacle & Stardance Direct Vent - Rear Vent Gas Heaters
20007066
Stove Dimensions - Pinnacle Direct Vent Gas Heater
16 ³⁄₈ "
(400mm)
26 ¹⁄₂ "
(673mm)
25 ¹⁄₄ "
(641mm)
22 ³⁄₈ "
(568mm)
24 ³⁄₈ "
(619mm)
17"
(432mm)
5"
(140mm)
3457
Flue Transition Connector
(For fireplace installation
only)
Fig. 1 PDV20 dimensions.
Stove Dimensions - Stardance Direct Vent Gas Heater
Fig. 2 SDVR dimensions.
7"
(178mm)
CL Valve
Inlet
26 ³⁄₄ "
(680mm)
25"
(635mm)
14"
(356mm)
3"
(76mm)
CL
Valve Inlet
24"
(610mm)
26"
(660mm)
3457
