4 – ENGLISH 5 – ENGLISH
SEt-UP
connecting the telephone
1 connect the curly cord to the handset and to the jack on the left
side of the telephone.
2 place the handset into the cradle.
3 Connect the telephone line cord to the TEL.LINE jack at the rear of
the unit.
4 connect the other end into the telephone wall jack. You will hear
a click when the modular plug is correctly in place.
connecting the Power Supply
plug the ac adapter into the ac power Jack on the back of your phone,
then into a standard electrical outlet or surge protector, if you are
using one.
Note: For safety reasons, use only the AC120v DC9v 300mA adapter
provided. The adapter is required for the telephone to work correctly.
Hanging the Phone on the Wall
You can place your phone on a flat surface or mount it on a telephone
wall plate (not included).
1 To mount using an existing wall plate adapter.*
2 connect one end of the short phone cord to the telephone wall
plate and the other to the telephone
3 Insert the supplied mounting bracket into the slots on the back
of the phone and push the bracket up until it clicks. To detach the
bracket, simply press the tab and slide down bracket down.
4 Insert the two keyhole slots on the phone with the wall plate and
slide the phone down, being careful not to pinch the telephone
line, until the phone is secure.
5 press and lift out the handset holder. remove the hanging peg
(located by the switch hook) by pushing it upwards then rotate
the peg 180 degrees, then snap it into place so it will hold the
handset in place when the phone is mounted on the wall.
*If you do not have an existing wall mount plate adapter they are
available at most major electronic and hardware retailers, simply
follow the manufacturer’s instructions for installation.
