9T425-16, 9T427-16, and 9T428-16 Module Specific Information
Token Ring Specific Configuration Screen
The Token Ring SpeciÞc ConÞguration Screen (Figure 1), allows you to conÞgure
each module port.
Figure 1. Token Ring Specific Configuration Screen
SmartSwitch 9000 Local Management
Token Ring Specific Configuration
Module Name: 9T428-16 Firmware Revision: 01.12.03
Slot Number: 14 BOOTPROM Revision: 01.02.00
Source Route Bridge Number(0-F): 1
Virtual Ring Number(000-FFF): CAC Auto-Detect Ring Number: [ENABLED]
Locally Admin Media Ring Bridging/ Novell C-Port Duplex
Port Address Rate Number Explorer Xlate Mode Mode
1 00-00-B8-00-94-58 [ 16M] 001 [SRT/ TP] [NONE] [STN/RI] [AUTO]
2 00-00-B8-00-94-D8 [ 16M] 002 [ SR/ARE] [NONE] [STN/RI] [AUTO]
3 00-00-B8-00-94-38 [ 16M] 003 [ TP/ TP] [ LLC] [STN/RI] [AUTO]
4 00-00-B8-00-94-B8 [ 16M] 004 [ TP/ TP] [NONE] [STN/RI] [AUTO]
5 00-00-B8-00-94-78 [ 16M] 005 [ TP/ TP] [ LLC] [ LOBE] [AUTO]
6 00-00-B8-00-94-F8 [ 16M] 006 [ TP/ TP] [NONE] [STN/RI] [AUTO]
7 00-00-B8-00-94-04 [ 16M] 007 [ TP/ TP] [NONE] [STN/RI] [AUTO]
8 00-00-B8-00-94-84 [ 16M] 008 [ TP/ TP] [NONE] [STN/RI] [AUTO]
SAVE RESET DEFAULTS
[ 9-16 ] EXIT RETURN
