9T425-16, 9T427-16, and 9T428-16 Module Specific Information
2
7 3 TOKEN RING 2 Token Ring 2 - Front Panel Port
8 4 TOKEN RING 3 Token Ring 3 - Front Panel Port
9 5 TOKEN RING 4 Token Ring 4 - Front Panel Port
10 6 TOKEN RING 5 Token Ring 5 - Front Panel Port
11 7 TOKEN RING 6 Token Ring 6 - Front Panel Port
12 8 TOKEN RING 7 Token Ring 7 - Front Panel Port
13 9 TOKEN RING 8 Token Ring 8 - Front Panel Port
14 10 TOKEN RING 9 Token Ring 9 - Front Panel Port
15 11 TOKEN RING 10 Token Ring 10 - Front Panel Port
16 12 TOKEN RING 11 Token Ring 11 - Front Panel Port
17 13 TOKEN RING 12 Token Ring 12 - Front Panel Port
18 14 TOKEN RING 13 Token Ring 13 - Front Panel Port
19 15 TOKEN RING 14 Token Ring 14 - Front Panel Port
20 16 TOKEN RING 15 Token Ring 15 - Front Panel Port
21 17 TOKEN RING 16 Token Ring 16 - Front Panel Port
Table 1. 9T425-16, 9T427-16, and 9T428-16 Token Ring Module Interfaces (Continued)
System
Interface
Number
Switch
Interface
Number
Interface
Name
Interface
Description
