Sample IMUX Configuration
HSIM-W87 User’s Guide 4-15
2. After all the desired channels have been added to the group (four were
put in the group in this example), the group must be enabled:
Enter: imux 1 -eg 1
The screen shows the response to the imux command to enable
group 1 in
Figure 4-4 .
Figure 4-4 Enabling the IMUX Group
3. The next step is to enable the imux application for imux 1:
Enter: imux 1 -ea
The screen in
Figure 4-5 displays the response to the command.
imuxsetup2
-> imux 1
#
# WAN Inverse Multiplexer 1 Status: Disabled
#
# Inverse WAN Available Xmit Byte Inverse
# Multiplexer Group Physical BW Count Multiplexer Channel
# ID Admin Status Number (bits/sec) (bytes) ID IfIndex Status
#-------------------------------------------------------------------------------------------------------------
# 1 Disabled 21 1536000 0 1 28 INACTIVE
# 1 Disabled 22 1536000 0 2 29 INACTIVE
# 1 Disabled 23 1536000 0 3 30 INACTIVE
# 1 Disabled 24 1536000 0 4 31 INACTIVE
#
#
# Number of WAN Inverse Multiplexer Groups currently programmed : 1
#
# Number of WAN Inverse Multiplexer Channels currently programmed : 4
-> imux 1 -eg 1
# Inverse Multiplexer group 1 enabled.
