Used in, Table 3-1 – Cabletron Systems HSIM-W87 User Manual
Page 26
Chapter 3: LANVIEW LEDs
3-2
HSIM-W87 User’s Guide
Table 3-1
HSIM-W87 LEDs
LED
Color
Definition
Processor
(CPU)
Off
Power Off
Green (solid)
Fully operational
Red (solid)
System in reset mode (temporary)
Link (LNK)
Red
No Link or Receive signal
Amber
Traffic on at least one port
Green
Link but sync may not be present
Status
(STS)
Off
Normal
Red
Red Alarm
Green (blinking)
Receiving Blue Alarm
Amber Yellow
Alarm
Amber (blinking)
Port is performing diagnostics
