Cleveland

Project ________________________________

Item __________________________________

Quantity _______________________________

FCSI Section ____________________________

Approval _______________________________

Date __________________________________

1333 East 179 St.,

Cleveland, Ohio, U.S.A. 44110

Tel: 1-216-481-4900

Fax: 1-216-481-3782

Web Site: www.ClevelandRange.com

Email: [email protected]

COMBI OVEN-STEAMER
Stacking Kits for Electric Table Type Models
(OEB 6.10 on OEB 10.10 or OES 6.10 on OES 10.10)

SECT.

IIB

PAGE

5F

0707

by

by

Cleveland

Cleveland

Model #

Description

CSTK-1010

for mounting one 6.10 model on top of one 10.10 model

CSTK-1010CA

for mounting one 6.10 model on top of one 10.10 model (with casters)

UNIT A

UNIT B

6.00"

RC

CS

W1

W2

D

4.38"

NOTE: Overall height of unit does not change for units with casters.

U

RC

CS

W1

W2

D

RC

CS

W1

W2

D

37.83"

NOTE: Overall height of unit does not change for units with casters.

LEFT SIDE VIEW

UNIT A

UNIT B

4.38"

48.54"

6

6.10
on 10.10
ELEC

3

7

8

.4

1

"

36.70"

1.58"

1.82"

2

8

.4

3

5.00"

3

8

.9

8

"

6.00

"

8

0

.0

0

(M

IN

.H

O

O

D

R

E

Q

U

IR

E

M

E

N

T

)

2.52"

UTILITIES

(Utility connection shown below are listed per unit)

Required Clearances:

Rear - 2", Left Side - 4", Right Side - 2 1/2"

• Allow for sufficient distance if a "high heat source" (i.e. Broiler) is located next to

the unit.

• Allow for sufficient clearance on left side for service access (contact the factory

service department for recommendations).

• Installation must comply with all local fire and health codes.

Electrical Requirements:

Do not connect to a G.F.I. outlet.

BOILER

UNIT A - OEB-6.10

UNIT B - OEB-10.10

MODELS

208/3/60 240/3/60

440/3/60 480/3/60

208/3/60 240/3/60 440/3/60 480/3/60

Total Connected Load:

9.9 KW

12.8 KW

11 KW

13.1 KW

16.4 KW 21.6 KW

18.5 KW 22 KW

Hot Air:

8.6 KW

11.4 KW

9.1 KW

10.2 KW

14.7 KW 19.6 KW

16.5 KW 19.6 KW

Steam Generator:

7.7 KW

10.2 KW

8.6 KW

10.2 KW

12.8 KW 17.1 KW

14.3 KW 17.1 KW

Amps per Phase:

27.3

30.8

15.2

16.3

45.5

51.8

24.2

26.4

BOILERLESS

UNIT A - OES-6.10

UNIT B - OES-10.10

MODELS

208/3/60 240/3/60

440/3/60 480/3/60

208/3/60 240/3/60 440/3/60 480/3/60

Total Connected Load:

9.9 KW

12.8 KW

11 KW

13.1 KW

6.4 KW

21.6 KW

18.5 KW 22 KW

Hot Air:

8.6 KW

11.4 KW

9.1 KW

10.2 KW

14.7 KW 19.6 KW

16.5 KW 19.6 KW

Amps per Phase:

27.3

30.8

15.2

16.3

45.5

51.8

24.2

26.4

W1

W2

D

RC

S

CS

AV

G

E1

Water Connections:

Cold Water (drinking water quality)

Flow Pressure:

30 - 60 PSI

Water Inlets:

3/4" GHT-F (Female Garden Hose

Connection)

Treated Water for Steam Generator

Untreated Water for Condenser

Drain Connection:

2" Tube

Venting:

Exhaust Hood required

*Connection for Cleaning Solution

*Connection for Rinse Cycle

*Available as an option

Note: For additional connection details,

see spec sheet for each individual

combi model to be stacked.

W1

W2

D

RC

S

CS

AV

G

W1

W2

D

RC

S

CS

AV

G

W1

W2

D

RC

S

CS

AV

G

E1

E2

W1

W2

D

RC

S

CS

AV

W1

W2

D

RC

S

CS

AV

G
