9084-OM (V4.0) 9084 PRODUCT MANUAL 3-17
Operating Instructions
9084 Function Submenu List and Descriptions
(continued)
• White Hard Clip Applies white hard clip (limiting) at specified percentage.
(50.0% to 109.1%; null = 109.1%)
• White Soft Clip Applies white soft clip (limiting) at specified percentage.
(50.0% to 109.1%; null = 109.1%)
• Chroma Saturation Clip Applies chroma saturation clip (limiting) chroma saturation at specified
percentage.
(50.0% to 160.0%; null = 160.0%)
Table 3-2 9084 Function Submenu List — continued
1 2 3 4
Proc
Clip
WHCL
(value) Clip value in percent;
0.1% precision
Vid
Card Edge Control Menu:
1 2 3 4
Proc
Clip
WSCL
(value) Clip value in percent;
0.1% precision
Vid
Card Edge Control Menu:
1 2 3 4
Proc
Clip
CSAT
(value) Clip value in percent;
0.1% precision
Vid
Card Edge Control Menu:
