Getting Started With Your System
9
EMM Three two-color LED status indicators,
one each for the two EMM SAS ports and
one for the EMM status
Power supply/cooling fan Three LED status indicators for power supply
status, power supply/fan fault, and AC status
Switch
System identification button Located on the front control panel.
This button is used to locate a system
within a rack.
Mode switch Located on the front control panel.
Used to switch the system between unified
and split mode operation.
Power Supplies
AC power supply (per power supply)
Wattage 600 W
Voltage 100–240 VAC (8.6 A–4.3 A)
Heat dissipation 188 W
Maximum inrush current Under typical line conditions and over the
entire system ambient operating range,
the inrush current may reach 55 A per
power supply for 10 ms or less.
Available Hard Drive Power (Per Slot)
Supported hard drive power
consumption (continuous) Up to 1.16 A at +5 V
Up to 1.6 A at +12 V
EMM Power (Per Slot)
Maximum power consumed by EMM 11 W at +12 V
Maximum available power 100 W at +12 V
Maximum available power 1 W at +5 V standby
LED Indicators (continued)
