8
Installation Guide
• Needle-nose pliers
• 4-mm Allen wrench (if you want to reverse the direction that
the front door opens)
• Keys to the rack doors and side panels
• 13-mm wrench (for rack removal from pallet)
• 17-mm wrench (for rack removal from pallet)
Removing and Replacing the Rack Doors
WARNING:
Because of the size and weight of the rack cabinet doors,
never attempt to remove or install them by yourself.
WARNING:
When storing the doors, lay the doors flat so they do not fall over
and accidentally injure someone.
Removing the Front Door
1 Pull the door latch and open the front door all the way (see Figure 1-1).
2 While holding the door, pull the hinge pin upward so that it clears the
door’s hinge-pin housing (see Figure 1-1).
The hinge pin’s retention clip prevents the hinge from being pulled out of
the hinge body.
