VRX610
13 12
VRX610
Switches among Radio, CD changer, MD changer and TV.
Functions of Remote Control Unit Buttons
Notes:
• The remote control unit does not work when the panel is closed.
• Some of the corresponding buttons on the main unit and remote control unit have different functions.
£ FUNC
¢ BAND
DISC UP
TOP
VOLUME
§ SEARCH
¶ PLAY/PAUSE
• MUTE
ª ISR
º DISP
MONI
⁄ PS/AS
SCN
¤ WIDE
RPT
‹ TV/VTR
RDM
VISUAL
Button
Mode
Radio
CD changer
MD changer
Switches reception band. Moves to the next disc in
increasing order.
Increases and decreases volume (in all modes).
Moves preset channels
up and down.
No function.
Moves tracks up and
down.
When pressed and held
for 1 second:
Fast-forward/
Fast-backward.
Switches between
playback and pause.
Turns mute on and off.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
No function.
No function.
Scan play.
When pressed and held
for 1 second: Disc scan
play.
Repeat play.
When pressed and held
for 1 second: Disc repeat
play.
Random play.
When pressed and held
for 1 second: Disc
random play.
TV
Moves preset channels
up and down.
No function.
Switches reception band.
Preset scan.
When pressed and held
for 2 seconds: Auto store.
Switches TV display size.
Switches the VISUAL mode.
Switches between TV and
VTR.
ISR on and off.
Turns on and off the monitor.
› Inserting the Batteries
1. Turn the remote control unit over, then slide
the rear cover in the direction of the arrow.
2. Insert the AA (SUM-3, IECR-6/1.5V) batter-
ies that came with the remote control unit
facing in the directions shown in the figure,
then close the rear cover.
Notes:
Using batteries improperly can cause them to explode.
Take note of the following points:
• When replacing batteries, replace both batteries
with new ones.
• Do not short-circuit, disassemble or heat batteries.
• Do not dispose of batteries into fire or flames.
• Dispose of spent batteries properly.
5. REMOTE CONTROL
Remote control unit
When the panel is open
1
WIDE
25
Switches the VISUAL mode.
