Bottom View
Using a Battery
Battery Performance
CAUTION:
Before you perform the following procedures, see the safety instructions in the Product
Information Guide.
NOTE:
For more information about the Dell warranty for your computer, see the Product Information
Guide or separate paper warranty document that shipped with your computer.
1 battery-bay latch releases (2) 5 hard drive
2 charge-gauge status button 6 Media Base docking-device
connector
3 battery charge gauge 7 memory module/coin-cell
battery cover
4 battery 8 fan air vents
7
1
5
6
8
3 4 2
