Cisco IOS Dial Services Quick Configuration Guide
Chapter 3 Configuring the Cisco 1604 Router
Step 6—Testing the Cisco 1604 Connection to the Cisco AS5300
Step 6 Enter additional commands as illustrated below to verify robo-austin’s connection with hq-sanjose:
robo-austin# show dialer map
Static dialer map ip 10.1.254.1 name hq-sanjose (14085551234) on BRI0
robo-austin# show dialer
BRI0 - dialer type = ISDN
Dial String Successes Failures Last called Last status
14085551234 1 0 00:00:30 successful
0 incoming call(s) have been screened.
0 incoming call(s) rejected for callback.
BRI0:1 - dialer type = ISDN
Idle timer (120 secs), Fast idle timer (20 secs)
Wait for carrier (30 secs), Re-enable (15 secs)
Dialer state is multilink member
Dial reason: ip (s=10.1.254.4, d=10.1.254.1)
Connected to 14085551234 (hq-sanjose)
BRI0:2 - dialer type = ISDN
Idle timer (120 secs), Fast idle timer (20 secs)
Wait for carrier (30 secs), Re-enable (15 secs)
Dialer state is idle
Virtual-Access2 - dialer type = IN-BAND SYNC NO-PARITY
Rotary group 0, priority 0
Idle timer (120 secs), Fast idle timer (20 secs)
Wait for carrier (30 secs), Re-enable (15 secs)
Dialer state is data link layer up
Time until disconnect 105 secs
Connected to 14085551234 (hq-sanjose)
robo-austin# show ppp multilink
Bundle hq-sanjose, 1 member, Master link is Virtual-Access2
Dialer Interface is BRI0
0 lost fragments, 0 reordered, 0 unassigned, sequence 0x0/0x0 rcvd/sent
0 discarded, 0 lost received, 1/255 load
Member Link: 1 (max not set, min not set)
BRI0:1
robo-austin# show interface bri 0:1
BRI0:1 is up, line protocol is up
Hardware is BRI
MTU 1500 bytes, BW 64 Kbit, DLY 20000 usec, rely 255/255, load 1/255
Encapsulation PPP, loopback not set, keepalive set (10 sec)
LCP Open, multilink Open
Last input 00:00:07, output 00:00:07, output hang never
Last clearing of "show interface" counters never
Queueing strategy: fifo
Output queue 0/40, 0 drops; input queue 0/75, 0 drops
5 minute input rate 0 bits/sec, 0 packets/sec
5 minute output rate 0 bits/sec, 0 packets/sec
472 packets input, 13496 bytes, 0 no buffer
Received 469 broadcasts, 0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
504 packets output, 18013 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 output buffer failures, 0 output buffers swapped out
104 carrier transitions
