I N S T A L L A T I O N I N S T R U C T I O N S
Small Flat Panel Lift Arm
FSA-1004 and KSA-1004
BEFORE YOU BEGIN
CAUTION: To prevent damage to the mount, which could affect or void the Factory warranty, thoroughly
study all instructions and illustrations before you begin to install the mount brackets. Pay particular atten-
tion to the “Important Precautions” on Page 2.
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-582-6480.
The Lift Arm FSA/KSA-1004 is an accessory that can be
used with a broad range of Small Flat Panel Displays.
The FSA/KSA-1004 allows the user to move a display
vertically up or down in a 13 inch radius. The lift arm can
be moved vertically 6-1/2” up from center and 6-1/2”
down from center.
The FSA/KSA-1004 is designed to safely hold a display
weighing up to 25 lbs. (11.3kg). The display can be up to
30 inches wide.
The FSA/KSA-1004 accommodates all VESA®
75mm/100mm compliant displays.
Lift Arm
