3

30" ELECTRIC DROP-IN RANGE INSTALLATION INSTRUCTIONS

A

C

1/2” min.

1/2” min.

1/4” min.

24" Min.

(61 cm Min.)

18" Min.

(45.7 cm Min.)

30" Min.

(76.2 cm Min.)

See Note 3

30"

(76.2cm)

Locate Cabinet Doors
1" (2.5 cm) Min.
from Cutout Opening

Shave Raised Edge
to Clear Space for a
31½" (81 cm) Wide
Cooktop Rim.

1½" Max.

(3.8 cm) Max

.

31½"

(81 cm)

Exact

App. 1-7/8"

(4.8 cm)

These surfaces should be fl at &
leveled (hatched area).

Smoothtop Models

NOTE: Two sets of holes are provided under anti-
tip bracket. Bracket is attached in the upper hole
position at the factory. Refer also to page 6, item 9
for additional details.

48" (122 cm)

Armored Cable

ANTI-TIP BRACKET

AT REAR OF RANGE

A. Cutout Width

(Countertop and

cabinet)

B. Cutout Depth

(According to front of

cabinet)

C. Height of

Cutout

30 ±

1/16

"

(76.2 ± 0.15 cm)

21 3/4" (55.2 cm) min

22 1/8" (56.2 cm) max

29" (73.7 cm)

27½" Min.

Front Filler
Support

Front Cabinet Filler

(If required)

Grounded Junction Box in
adjoining Cabinet

Cutout Dimensions
