Baumer TXG cameras User Manual
Baumer Sensors
Product Specification
TXG series – Innovative functionality in compact design
Output of excellent 8 / 12 bit image data
▪
VGA up to 5 megapixel, monochrome and color
▪
RGB and YUV interpolation algorithms on board
▪
Bandwidth up to 1000 Mbit/sec for fast multi-camera operation
▪
Flexible system architecture due to cable length up to 100 m
▪
Baumer driver for reliable image transfer
▪
Camera Type
Sensor
Size
Resolution
Full Frames
[max. fps]
Monochrome / Color
TXG02 / TXG02c
1/4“
656x494
140
TXG03 / TXG03c
1/3"
656 x 494 / 656 x 490
90
TXG04
1/2"
656 x 494
56
TXG06 / TXG06c
1/2"
776 x 582 / 776 x 578
64
TXG08 / TXG08c
1/3"
1032 x 776 / 1032 x 772
28
TXG12 / TXG12c
1/3“
1296x966
32
TXG13 / TXG13c
1/2"
1392 x 1040 / 1384 x 1036
20
TXG14 / TXG14c
2/3"
1392 x 1040 / 1384 x 1036
20
TXG14f
2/3"
1392 x 1040
30
TXG20 / TXG20c
1/1.8"
1624 x 1236 / 1624 x 1232
16
TXG50 / TXG50c
2/3"
2448 x 2050 / 2448 x 2050
15
System Requirements
Single-camera system
Multi-camera system
Minimum
Recommended
Minimum
Recommended
CPU
Intel
®
Pentium
®
4
or comparable
processor
Intel
®
Core™ Duo comparable processor
Clock
2.5 GHz
> 2.5 GHz
2.5 GHz
3 GHz
RAM
1024 MB
2048 MB
2048 MB
> 2048 MB
Operating
system
(OS)
Microsoft
®
Windows
®
XP incl. Service Pack 2 or higher
Microsoft
®
Windows
®
XP x64 incl. Service Pack 2 or higher
Microsoft
®
Windows Vista™ 32 / 64 bit systems
Microsoft
®
Windows 7 32 / 64 bit systems
Linux
®
32 / 64 bit systems from Kernel 2.6.xx
Graphic
recommended resolution 1280 x 1024, color depth at least 16 bit
Ethernet
Gigabit Ethernet compliant NIC (recommended Intel
®
chipset)
Framework
(optional)
Windows
®
OS: NET™ Framework 2 0 or higher
Linux
®
OS: Mono 1 2.4 or higher
Dimensions
● Standard Cameras with IP67 housing:
56
56
4x
M
5
C Mount
62
M
x
1,
5
58 3
Ø
65
● Protective Caps IP67:
51,8
61,8
70,8
93,8
Ø
65
Dimensions
● Standard Cameras:
26
26
36
36
4x
M3
36
36
26
8x
M
3
48
C-Mount
6,5
● Standard Cameras with Power over Ethernet (PoE):
26
26
36
36
4x
M3
36
36
26
8x
M
3
57,7
C-Mount
6,5
● Standard Cameras with additional I/Os:
26
26
36
36
4x
M3
36
36
26
8x
M
3
48
C-Mount
6,5
Safety
Further Information
For further information on our products visit www.baumer.com
For technical issues, please contact our technical support:
[email protected] Phone +49 (0)3528 4386-0 Fax +49 (0)3528 4386-86
© Baumer Optronic GmbH Badstrasse 30 DE-01454 Radeberg, Germany
Technical data has been fully checked, but accuracy of printed matter not guaranteed.
Subject to change without notice. Printed in Germany 07/13. v4.5
11037533
FCC – Class B device
N
ote
: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursu-
ant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interfer-
ence in a residential environment. This equipment gener-
ates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructios,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occure in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off an
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
▪
Increase the separation between the equipment and the
▪
receiver.
Connect the equipment into an outlet on a circuit different
▪
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
▪
for help.
Conformity:
CE, FCC Part 15 Class B, UL (standard cameras only), RoHS
UL – Class III device
▪
The power supply to operate the
TXG series of cameras must be real-
ized using a limited power supply in
accordance to UL60950.
Safety Precautions
Protect the sensor from dirt and
▪
moisture.
Never open the camera housing.
▪
Avoid camera contamination by
▪
foreign objects.
Environmental requirements:
Storage temp.
-10°C ... +70°C
Operating temp.
+5°C ... +50°C
Housing temp.
max. +50°C
Humidity
10 % ... 90 %
Non-condensing
Tested according to standard
EMVA 1288
Quick Start Guide
TXG Gigabit Ethernet cameras
Tube Length
[mm]
Item No.
51,8
11008777
61,8
11008776
70,8
11008775
93,8
11008774
Latest software version and technical
documentation are available at:
