Operation
Legend 300E Spot User Manual Rev. 01g -13-
Fixture Settings From the Main Menu, highlight Fixture Settings and press (a new menu with
the fixture settings will open).
Reverse Pan Direction
1) Highlight Pan Inverse (the current setting will show).
2) To reverse the pan direction, press (a pop up window will open).
a) Select YES to reverse the pan direction or NO to use the normal pan direction.
b) Accept the selected option.
Reverse Tilt Direction
1) Highlight Tilt Inverse (the current setting will show).
2) To reverse the tilt direction, press (a pop up window will open).
a) Select YES to reverse the tilt direction or NO to use the normal tilt direction.
b) Accept the selected option.
Head Motion Black Out
1) Highlight Bl.o P/T Moving (the current setting will show).
2) To black out the output when the head moves, press (a pop up window
will open).
a) Select YES to black out the output when the head tilts or pans, or NO to keep
the output on while the head moves.
b) Accept the selected option.
Color Change Black Out
1) Highlight Bl.o Color Change (the current setting will show).
2) To black out the output when the color wheel changes, press (a pop up
window will open).
a) Select YES to black out the output during a color change or NO to keep the
output on to see the color changing.
b) Accept the selected option.
Gobo Change Black Out
1) Highlight Bl.o Gobo Change (the current setting will show).
2) To black out the output when the gobo wheel changes, press (a pop up
window will open).
a) Select YES to black out the output during a gobo change or NO to keep the
output on to see the gobo changing.
b) Accept the selected option.
