Operation
-12- Legend 300E Spot User Manual Rev. 01g
DMX Functions From the Main Menu, highlight DMX Functions and press (a new menu with
the DMX functions will open).
DMX Address
1) Highlight DMX Address (the current address will show).
2) Press
3) To change the current address, press (a pop up window will open).
a) Change the starting address (001~512).
b) Accept the new value.
DMX Mode
1) Highlight DMX Channel Mode (the current mode will show).
2) Press
3) To change the current mode, press (a pop up window will open).
a) Select a DMX mode (Mode 1/Mode 2).
b) Accept the selected option.
View DMX Values
1) Highlight View DMX Value.
2) Press
3) Press (the value for each of the attributes of the current DMX mode will
show).
a) Scroll along the list to see the values of all the current attributes.
b) Return to the previous menu.
The list will show either 17 or 25 attributes, depending on the current DMX mode.
W-DMX Settings
1) Highlight WDMX Setting
2) Press
3) To see the WDMX settings, press (a sub-menu will open).
4) Press
5) To activate or deactivate W-DMX, highlight Active (the current setting will show)
and press (a pop up window will open).
a) Select YES to activate W-DMX or NO to deactivate W-DMX.
b) Accept the selected option.
6) To enable or disable retransmission, highlight Retransmit (the current setting will
show) and press (a pop up window will open).
a) Select YES to enable retransmission or NO to deactivate retransmission.
b) Accept the selected option.
7) To reset the memory, highlight Reset Memory and press (a pop up
window will open).
a) Select YES to reset the memory or NO to exit without resetting.
b) Accept the selected option.
8) Return to the previous menu.
The W-DMX functionality requires the W-DMX transceiver installed on the Legend
300E Spot fixture.
