QuickMedia™ Distribution Amplifier Crestron QM-DA
QM-DA Overall Dimensions (Front View – QM-DA-8 Shown)
19.01 in
(48.29 cm)
1.70 in
(4.32 cm)
17.03 in
(43.25 cm)
1
QM-DA-4 & QM-DA-8 Overall Dimensions (Bottom View - QM-DA-8 Shown)
6.64 in
(16.86 cm)
QM-DA-16 Overall Dimensions (Bottom View)
10.14 in
(25.75 cm)
4 • QuickMedia™ Distribution Amplifier: QM-DA Operations Guide – DOC. 6547A
