QuickMedia™ Distribution Amplifier Crestron QM-DA
Features and Functions
• QuickMedia signal distribution amplifier
1 to 4 in QM-DA-4
1 to 8 in QM-DA-8
1 to 16 in QM-DA-16
• Easy single cable connections
• No control or adjustments necessary
• Single space rack mountable
• Built-in Cresnet ® distribution
• Built-in Cresnet hub/repeater (QM-DA-16 only)
Specifications Specifications
Specifications for the QM-DA are listed in the following table. Specifications for the QM-DA are listed in the following table.
QM-DA Specifications QM-DA Specifications
SPECIFICATION SPECIFICATION DETAILS DETAILS
Video/RGB
DA
Distribution amplifier
1 to 4 in QM-DA-4
1 to 8 in QM-DA-8
1 to 16 in QM-DA-16;
distributes QM video input signal to all outputs
4 in QM-DA-4
8 in QM-DA-8
16 in QM-DA-16
Gain 0 dB
Audio
DA Distribution amplifier
1 to 4 in QM-DA-4
1 to 8 in QM-DA-8
1 to 16 in QM-DA-16;
distributes QM audio input signal to all outputs
4 in QM-DA-4
8 in QM-DA-8
16 in QM-DA-16
Gain 0 dB
Power
Cresnet Power Usage QM-DA-4: 10 Watts (0.41 Amps @ 24 Volts DC)
QM-DA-8: 16 Watts (0.66 Amps @ 24 Volts DC)
QM-DA-16: 24 Watts (1.00 Amps @ 24 Volts DC)
Environmental
Temperature 41º to 104ºF (5º to 40ºC)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation QM-DA-4: 33 BTU/Hr
QM-DA-8: 54 BTU/Hr
QM-DA-16: 81 BTU/Hr
(Continued on following page)
2 • QuickMedia™ Distribution Amplifier: QM-DA Operations Guide – DOC. 6547A
