5. Disconnect the negative (-) 12V battery cable (1).
Insulate the negative (-) battery cable terminal with
insulated tape.
NOTE:
: Arrow in illustration depicts vehicle front
direction.
6. Wait at least ten (10) minutes for complete discharge of the high voltage capacitor after the fuses
are pulled.
7. Perform the dismantling operation.
To avoid unintended reinstallation and risk of electrical shock and severe personal
injury or death, the dismantler should carry the fuses on his/her person and cover the fuse
box with insulated tape.
3-3.6 Alternate Procedure 2
• Do not remove the service plug without always wearing appropriate PPE to help
protect the dismantler from serious injury or death by electrical shock.
• Immediately cover the service plug socket with insulated tape. The Li-ion battery
retains high voltage power even when the service plug is removed. To avoid electric
shock, DO NOT touch the terminals inside the socket.
To avoid unintended reinstallation and risk of electrical shock and severe personal injury
or death, the dismantler should carry the service plug on his/her person while work is in
progress.
1. Locate the carpet flap (1) behind the center console on
the floor raised area. At the notched area (A) pull up on
the carpet flap (1).
NOTE:
: Arrow in illustration depicts vehicle front
direction.
1
AAYIA0092ZZ
AAYIA0116ZZ
