Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
209 — Front Wiper Hi/Lo Relay
301 — Fuel Pump Relay
302 — Trailer Tow Battery Charge Relay
303 — Not Used
304 — Powertrain Control Module Relay
305 — Fuel Pump Hi/Lo Relay
(Supercharged engine only)
306 — Inertia Switch Relay
(Supercharged engine only)
401 — Not Used
501 — Powertrain Control Module Diode
502 — A/C Compressor Diode
503 — Not Used
601 CB Power Windows, Moonroof
602 — Not Used
*Mini fuses **Maxi fuses
CHANGING THE TIRES
If you get a flat tire while driving, do not apply the brake heavily.
Instead, gradually decrease your speed. Hold the steering wheel firmly
and slowly move to a safe place on the side of the road.
Spare tire information
Your vehicle is equipped with a spare tire that may be used as a spare or
a regular tire. The spare tire wheel may not match the road wheel, and is
not equipped with wheel trim. The wheel trim from the wheel/tire may
be used on the spare if the wheels match.
If your vehicle is equipped with 4WD, a spare tire of a different
size than the road tires should not be used. Such a tire could
result in damage to driveline components and make the vehicle
difficult to control.
Roadside Emergencies
220
