damage to the internal components or cracking of the container. As a
battery approaches a discharged state it becomes easier for the
electrolyte to freeze. If it freezes and expands it may crack the battery
case.
Alternator— police
The high-output alternator provides 200 amperes of current to support
the high power requirements of modern police equipment. Output at idle
is approximately 130 amperes. Current demand by both the vehicle and
all energized police equipment in excess of this amount during vehicle
idling will place the electrical system into a discharge condition.
Electrical power management systems should be applied if necessary to
avoid discharging the battery.
Power distribution connector
Power for aftermarket equipment can be obtained from the power
distribution connector located under the glove compartment. This
connector contains several fused power feeds and inputs available for the
addition of accessories. The following tables show the circuits available
for equipment.
Police
Pin Function Gauge Color
1 5A Start 18 Red/Black
2 Vehicle speed signal 18 Gray/Black
3 Battery saver 18 Dark green/Light green
4 20A Battery 14 Light green
5 15A Battery 18 Orange/Light green
6 50A Battery 10 Tan/Yellow
7 20A Run/Acc 14 Pink
8 20A Battery 14 Light Blue/White
9 20A Run/Acc 14 Tan
10 Hazard out 18 Black/Yellow
11 50A Battery 10 Red/White
12 Hazard In 18 Gray/White
Crown Victoria Severe Duty
