Fixed code programming
Note: Do not program the Car2U
௡ system with the vehicle in the garage.
Make sure that your key is on and engine off while programming the
transmitter.
1. To program units with fixed code DIP switches, you will need the
garage door hand-held transmitter, paper and a pen or pencil.
2. Open the battery cover and record the switch settings from left to
right for all 8 to 12 switches. Use the figure below:
When a switch is in the up, on, or + position, circle “L.”
When a switch is in the middle, neutral, or 0 position, circle “M.”
When a switch is in the down, off, or – position, circle “R.”
Switch position 1 2 3 4 5 6 7 8 9 10 11 12
Up, on or + L L L L L L L L L L L L
Middle, neutral or 0 M M M M M M M M M M M M
Down, off or – R R R R R R R R R R R R
L=left; M=middle; R=right
