Fuse/Relay
Location
Fuse Amp
Rating
Protected circuits
F14 25A** Rear power window (without
DCU)
F15 25A** DPS6
F16 — Not used
F17 — Not used
F18 20A** Front wiper motor
F19 5A* ABS/ESP 15 feed
F20 15A* Horn
F21 5A* Stop light switch
F22 15A* Battery monitor system
F23 5A* Relay coils, Light switch module
F24 — Not used
F25 10A* Power exterior Mirror (without
DCU)
F26 15A* TCM 30 feed automatic
transmission
F27 15A* A/C Clutch
F28 5A* TMAF fuel relay feed
F29 — Not used
F30 — Not used
F31 — Not used
F32 10A* EGR Valve, Swirl control valves,
Heated oxygen sensors
F33 10A* Ignition Coils
F34 10A* Injectors
F35 5A* Active grill shutter
F36 10A* ECM
F37 — Not used
F38 15A* ECM / TCM 15 feed
F39 — Not used
F40 5A* EPAS 15 feed
F41 20A* BCM 15 feed
