Hitches, Safety chains, 250 towing – FORD 2013 Edge v.4 User Manual
Page 251
Trailer Towing Connector (Vehicles Equipped with a Trailer-towing
or Prep Package)
The trailer towing connector is located under the rear bumper, on the
left side of your vehicle.
You must use a four-pin trailer wiring connector for
your vehicle and the trailer lighting equipment.
Color
Function
1. Dark Green
Right turn signal, brake lamp and hazard flasher
2. Yellow
Left turn signal, brake lamp and hazard flasher
3. Brown
Tail lamps and parking lamps
4. White
Ground
Hitches
Do not use a hitch that either clamps onto the bumper or attaches to the
axle.
Distribute the trailer load so 10-15% of the total trailer weight is on the
tongue.
Safety Chains
Note: Never attach safety chains to the bumper.
Always connect the safety chains to the hook retainers of your vehicle
hitch.
To connect the safety chains, cross them under the trailer tongue and
allow enough slack for turning tight corners. Do not allow the chains to
drag on the ground.
250
Towing
2013 Edge (edg)
Owners Guide gf, 4th Printing, November 2012
USA (fus)
