Instrument cluster – FORD 2013 C-MAX Hybrid v.1 User Manual
Page 88

EV Now
E144814
Illuminates when you select this
feature on. See Hybrid Electric
Vehicle (page 130).
EV Later
E151263
Illuminates when you select this
feature on. See Hybrid Electric
Vehicle (page 130).
Fasten Safety Belt
It will illuminate and a chime will
sound to remind you to fasten
your safety belt. See Safety
Belt Minder (page 30).
Front Airbag
If it fails to illuminate when you
start your vehicle, continues to
flash or remains on, it indicates
a malfunction. Have the system checked
by your authorized dealer.
Front Fog Lamps
(If Equipped)
Illuminates when you switch the
front fog lamps on.
High Beam
Illuminates when you switch the
high beam headlamps on. It will
flash when you use the
headlamp flasher.
Liftgate Ajar
E162453
Illuminates when the liftgate is
not completely closed.
Low Battery
(If Equipped)
E144691
Illuminates when the battery
level is low. May also be
accompanied by a message
suggesting the driver reduce usage of the
climate system.
Low Fuel Level
Illuminates when the fuel level
is low or the fuel tank is nearly
empty. Refuel as soon as
possible.
Low Tire Pressure Warning
Illuminates when your tire
pressure is low. If the lamp
remains on with the engine
running or when driving, check
your tire pressure as soon as possible.
It will also illuminate momentarily when
you switch the ignition on to confirm the
lamp is functional. If it does not illuminate
when you switch the ignition on, or begins
to flash at any time, have the system
checked by your authorized dealer.
Overdrive Cancel and Grade Assist
(If Equipped)
E162456
Illuminates when the overdrive
function of the transmission has
been switched off and the grade
assist function has been switched on.
Parking Lamps
Illuminates when you switch the
parking lamps on.
85
Instrument Cluster
