33
Freedom Designs, Inc. SP3 “Mini” Series
Main Frame
continued…..
Angle Adjustable Footboard…….
5. To change the height of the footboard on
the frame, loosen the 2 hex head
s c r e w s
on the footboard frame clamps. Set the
desired height and tighten.
Warning: In all footplate and hanger
adjustments, be sure that all screws are
tightened securely for your safety.
Quick Release Axle*
The
SP3 “Mini” is equipped with double lock
quick release axles that release with the push
of a button. This double lock quick release
mechanism allows the rear wheels to be easily
removed for transportation or storage.
To remove the rear wheel:
1. Unlock the wheel lock.
2. Grasp the frame with one hand.
3. With the other hand, squeeze the quick
release button.
4. The wheel will then pull off easily.
Warning: the axle is not properly locked
until the outside quick release button pops
out to its full extended position.
The lowest point of the footrest plate should
be at least 2 1/2” from the ground to ensure
the proper clearance.
*Patented
