1-888-628-1730 • Maxx Flow Installation Manual 7
11. If installing ONLY the H&S Maxx Flow intake manifold, slide the previously removed factory 3”
clamp onto factory intercooler pipe. If installing H&S Boost Tube, slide supplied 4” clamp onto boost
tube and slide the supplied 4” straight coupler onto boost tube.
12. Remove MAP sensor from factory intake manifold and install in H&S intake manifold.
13. Clean old gasket material off of head surface. Install new OEM gasket on head surface, sticky side
down. Apply a small amount of grease to top side of gasket (helps prevent gasket from breaking if
intake manifold must be removed again).
