18 Ford 6.7L Powerstroke EGR/Cooler Delete Installation Manual
1-888-628-1730 • www.hsperformance.com 19
Slide the three supplied 8mm washers onto the three supplied 8mm bolts. Using the hardware,
install the coolant block-off plate (largest plate). Tighten.
STEp 27
Remove the rear-left (passenger side closest to the firewall) bolt on the black intake “Y”. Using fac-
tory bolt, loosely install supplied Pressure Sensor Bracket. Using supplied small bolt, washers, and
nut, bolt previously installed bracket to the pressure line hook-bracket. Tighten all hardware.
STEp 28
