STEp 14
STEp 13
12 Ford 6.7L Powerstroke EGR/Cooler Delete Installation Manual
Unplug harnesses from the Powertrain Control Module (PCM) located on the passenger side firewall.
Tuck harnesses away from EGR system.
Unplug the three harnesses located on top of the EGR cooler. The orange harness has a yellow lock
tab that must be slid out before the harness can be unplugged. The black harness has a metal lock-
ing clip that must be pried out before the harness can be unplugged. Re-install the metal locking
clip after unplugging to prevent losing the small clip.
