STEp 20
STEp 19
14 Ford 6.7L Powerstroke EGR/Cooler Delete Installation Manual 1-888-628-1730 • www.hsperformance.com 15
Remove the four 8mm bolts from the short EGR pipe and remove the short EGR pipe from vehicle.
Retain bolts and gaskets for later use.
Remove the two 8mm bolts from the bracket holding the long EGR pipe to the EGR cooler. Remove
the four remaining 8mm bolts from the long EGR pipe and remove the long EGR pipe from vehicle.
Retain bolts and gaskets for later use.
