Adjustable fuel pump series, Installation – FASS FA D08 220G User Manual
Page 5
220 GPH
16 PSI (Approximately)
Adjustable Fuel Pump Series
A fuel pressure gauge is highly recommended to identify fuel filter life and to prevent engine damage!
Installation
Step 1: Install Electrical Harness
Step 2: Prepare Suction and Return Lines
Step 3: Mount Fuel System
Step 4: Install Fuel Line
Step 5: Check/Set Pressure
Step 6: Review Installation
“E”
To Engine
‘T’
Fuel Inlet Port
Boost
Compensation
Port
Adjustment Lock Nut
Set screw
Fuel Pressure Port
