B. For fitting purposes. Secure PBR-2001 to pump assembly lightly with (3) 1/4”-20x1 3/4 bolts and (3)
WA-1001D. This will assembly will be used in future steps for correct fitting of brackets. (Note:
Bracket maybe flipped to accommodate your application.)
D. Secure PFB-2002 and RS-2001 with bed bolt in previous step.
C. Unbolt driver side front bed bolt from bed retain bolt for future use. Align RS-2001 with PFB-2002.
.
E. Connect factory plug into the FASS harness. Plug FASS harness into the fuel module in tank. Make
sure to lock red slide tab. Connect female plug of the FASS harness into pump. Turn key to “on”. With
pump operating (you may have to bump the starter), turn pump over, liberally spray WD-40 (or equiva-
lent) into water separator nipple lubricating Gerotor.
